Features

• LTE-FDD B2/B4/B5/B17
• Tri-Band UMTS/HSDPA/HSPA+ B2/B5/AWS
• LTE-FDD/Rel-9 Cat3
• HSPA+ DC-HSPA+, Rel-10 HSPA+
• GNSS gpsOne Gen 8B, standalone, assisted, XTRA
• GPRS mobile station class B
• Control via AT commands or Gobi API
• Supply voltage range: 3.3 ~ 4.2 V
• Low power consumption
• Dimension: 30*30*2.9mm
• Operation temperature: -40C to +80C
• Jamming detection

Specifications for data transfer

• LTE: Uplink up to 80mbps. downlink up to 100mbps
• HSPA+: Uplink up to 5.76mbps. downlink up to 42mbps
• UMTS: Uplink/downlink up to 384kbps
• CSD: WCDMA data rate 57.6kbps,
• WCDMA 64Kbps CSD for video call

Interfaces

• USB2.0, UART, SIMCARD, SPI, I2C, GPIO, RTC, ADC, PCMM

Certifications

• PTRCB, ATT, ROHS, REACH
