Features

• Form factor: LCC+LGA, 77PIN
• Supply voltage range: 2.7V-4.8V
• LTE RF Power Class: 5 (Typ. 21dbm)
• TCP/UDP
• HTTP/HTTPS/TLS/DTLS/PING/LWM2M/COAP/MQTT
• Firmware update via USB, FOTA
• Operation temperature: -40°C to +85°C
• Dimensions: 17.6 X 15.7 X 2.4 mm
• Weight: 1.4g±0.2g

Frequency Bands

• CAT-M:
  B1/B2/B3/B4/B5/B8/B12/B13/B14
  B18/B19/B20/B25/B26/B27/B28/B66/B85
• CAT-NB:
  B1/B2/B3/B4/B5/B8/B12/B13/B18
  B19/B20/B25/B26/B28/B66/B71/B85

Data Transfer Rate

• Cat-M: Uplink: 1119Kbps Downlink:589Kbps
• NB-IoT: Uplink: 150Kbps Downlink:136Kbps

Interfaces

• UART, SIM card, PCM/I2S/SPI, USB
• I2C, GPIO, ADC, Embedded SIM (optional)

Consumption

• PSM: 3.2uA
• Sleep: 0.6mA @PTW=40.96s eDRX=81.92s
• Idle: 10mA

Certifications

• RoHS\REACH\JATE\Telec\Docomo\KDDI
• Softbank\RCM\CE(RED)\GCF\Deutsche Telekom\
• FCC\PTCRB\AT&T\Verizon\T-Mobile\US Cellular\IC
